Udder Mister® Express

Speed + Accuracy in a Small Footprint

FutureCow’s Udder Mister Express is a fully automated teat dip sprayer specifically designed for rotary parlors. The Udder Mister works with most standard teat dips automatically spraying teats prior to milking or after milking clusters are removed.

How Does It Work?

  • Udder Mister express automatically sprays teats with your preferred teat dip, fully coating and protecting from mastitis-causing bacteria between milkings.

  • Once installed, the Udder Mister requires no interaction from parlor staff except for basic routine maintenance.

  • The system uses sensors to detect when a cow is present. Its automated arm then extends, precisely spraying all teats simultaneously with dual nozzles. After each application the arm retracts and a wash-down system thoroughly cleans the nozzles, ensuring optimal efficiency for every cow.

  • The system is adjustable with customized spray nozzles to ensure full coverage based on your parlor set-up. Spray arm height is also adjustable. The Udder Mister arm is mounted on springs allowing the unit to flex 90 degrees in either direction to ensure it won't get caught on the rotary.

    Put an End to Costly Manual Dipping

    The Udder Mister teat dip sprayer is built to last under tough conditions.   The system automatically sprays teats with your preferred pre-dip or post-dip solution in record time - ideal for faster-moving rotary systems. As a result, it fully coats and protects teats from mastitis-causing bacteria between milking.

    • Eliminate expenses for one labor position per shift

    • Save money without sacrificing udder health

    • Prevent mastitis and its associated costs

    • See a full return on investment in 6 months

      Benefits of Udder Mister

      • Specifically placed sensors ensure every cow is sprayed properly, every time
      • Compatible with most standard teat dip sprays
      • Control and adjust spray position, dwell time and speed
      • Waste reducing sensors skip empty stalls and detect if milking clusters are still attached
      • Built to perform under all temperature conditions with our prep solution warmer

      Technical Specifications

      • Dip Usage: less than 17.5 ml per cow depending on dip viscosity and nozzle
      • Rotary Speed: options available up to 3.6 seconds per stall
      • Electricity: 120/240 VAC
      • Air: 90 psi

      Request More Information

      The Udder Mister teat dip sprayer is easy to add to any parlor.  The Udder Mister 1.0, Udder Mister 2.0, Express and Walkover options are all available to install around the world.
